Setting the Benchmark for Future-Proof Mechanical CPR
The corpuls cpr has redefined the standard for the next generation of automatic chest compression devices used by the emergency medical services and hospitals to achieve the best possible patient outcome in a cardiac arrest.
It is now more important than ever to protect our Emergency Services Personnel; with the corpuls cpr arm, Paramedics and hospital staff can be stood back from the patient whilst controlling the chest compressions from a safe distance away, providing uninterrupted automatic therapy.
Key Features
Why choose the corpuls cpr
Compression Parameters
Compression Frequency: 80-120 compressions/min
(individually adjustable in increments of 1 compression/min).
Compression Depth: 2 - 6 cm
(individually adjustable in increments of 0.1 cm).
Therapy Mode: 30:2 / 15:2 / continuous.
Patient Parameters
Thorax Height: 14 - 34 cm.
No restrictions regarding the patient’s weight and breadth of thorax.
Approved for use on children from the age of 8.
Energy Management
Lithium polymer (LiPo) batteries, each with 90 minute runtime.
Battery charging time via magnetic plug (no therapy): approx. 105 min: 0–80% then approx. 30 min: 80-100%
User-Friendly Operation
Therapy start/stop button with alarm function and 4 soft keys
Simultaneous display of operating mode, compression depth, compression frequency, time/therapy time/remaining battery time in minutes/percent
Back Boards
All of the back boards are radiolucent, and made from carbon fibre material, making them easy to clean and disinfect after use. For optimal effectiveness in all areas of rescue and resuscitation, three different boards are available...
Rec Board
Designed specifically for pre-hospital treatment. Attachment straps allow it to be fixed to any standard stretcher system.
Quad Board
Designed specifically for in-hospital treatment. Boards are radiolucent material to ensure the use of radiology equipment is not compromised at any time.
Scoop Board
Designed specifically for use with a scoop stretcher or vacuum mattress. Also features the securable straps to attach to any standard stretcher system.
Reusable Compression Pads
The compression pads come in two sizes and can be disinfected with all common agents. This helps to keep running costs to a minimum and ensures the corpuls cpr can be deployed on every CPR job without financial worries in the back of operators’ head.
Carrying Bag Pack
The corpuls cpr comes in an ergonomic, hig quality bag pack that is capable of storing all relevant accessories in designated compartments. The material is easy to wipe clean, and comes with an elasticated shoulder strap for seamless transportation to the emergency location.
Revolutionary Design
The corpuls cpr rotating arm grants free access to the patient's thorax at all times. The arm itself is mounted to one side, but the swivel function allows the range of movement to accurately position the device to give uninterrupted chest compressions.
With two joints and a height adjustable arm the corpuls cpr can be quickly adapted to the patient‘s body. It guarantees the optimal pressure point during therapy. Compression depth and mode can be easily adjusted. This design allows the quick switch from manual to automated chest compressions in matter of seconds.
The intuitive user interface features a therapy start/stop button with alarm and 4 softkeys. Alarm will sound if the arm is not placed at the correct depth to give the patient accurate chest compressions.Seamless Synchronisation with the C3T and corpuls3
Resuscitation can quickly become stressful. Thanks to the Bluetooth connection, the corpuls cpr is effectively the fourth module of the corpuls defibrillators. Complete synchronisation between the two devices provides a step change in resuscitation. Key advantages;
- Increased safety for the paramedics and the patient, perfect in tight spaces and during transport (land/air)
- Minimised interruptions - fatigue-proof therapy
- Improved chest compression fraction
- Adjust depth and frequency of compressions to meet your requirements even when not next to the patient
corpuls simulation
Don't just buy the best. Train to be the best with corpuls simulation. Control the physiological signals, vital parameters and scenarios presented to your trainees, providing the most realistic training available. Review performance data and guide improvements. Being the best is in your control.
The corpuls simulation device has bluetooth capability, allowing you to easily connect to your cpr arm, ensuring all staff are effective in using all products and technologies to their full potential.
Linked together with the corpuls simulation COMMUNITY, you're also able to collaborate with colleagues around the globe, sharing scenarios, data and performance metrics. All aimed at making you the best. Training never need be boring again.
Key Design Advantages for EMS Treatment
- Can be set up and deployed within seconds
- The Rec Board and Scoop Board are designed specifically for EMS use, with attachment straps allowing the boards to be fixed onto any standard stretcher system
- Patient tailored therapy which is easily adjustable
- Operating time 90 minutes with a display of the remaining run time in minutes
- LED indication of battery charge level in 20% increments
- Battery charging time (via magnetic connector, no therapy): 105 min 0-80% 30 min 80-100%
Key Design Advantages for In-Hospital Treatment
- Designed to be set up and deployed within seconds - can be left in standby until it is needed during difficult cardiac procedures in theatres.
- No limitations with accessing the patient’s thorax due to the rotating arm.
- The Quad Board has been specifically designed for in-hospital use. This low profile board can be deployed at any time and will still be comfortable for the patient to lay on.
- All compression boards available are made of radiolucent material to ensure the use of radiology equipment is not compromised at any time.
